AC Hardwired Interconnected

• Interconnectable with up to 24 devices (of which 18 can be initiating) including smoke, CO and heat alarms.
• 9V Battery backup provides protection in case of power failure.
• Test / Reset Button tests the unit for proper operation. Resets the carbon monoxide alarm.
• Tamper resist to deter battery and alarm theft.

• Combined Smoke & Carbon Monoxide Alarm – A single unit can be installed where previously, two were needed. Reduces installation time and protects against both fire and carbon monoxide dangers.
• AA Front-Loading Battery Backup – Change batteries without the need to remove the unit from the ceiling, providing continuous protection in the case of a power outage.
• Voice Warning - Warns of hazard by announcing “Fire!” or “Warning, Carbon Monoxide.”
• Tamper Resistant – Unit will lock to mounting bracket to deter theft or tampering.
• Alarm Memory: The green LED will flash every second during alarm. When the alarm condition goes away, the originating alarm unit will flash the green LED every 16 seconds until the Test / Reset button is pressed, thus resetting the alarm.
• Peak Level Memory – Announces “CARBON MONOXIDE PREVIOUSLY DETECTED” if alarm has detected a CO level of 100ppm or higher since it was last reset.
• Hush™ Feature – Silences nuisance alarms for approximately 9 minutes.
• cUL- and CSA-Listed

• AC-Wire with battery backup Powered by home's electricity in order to provide continuous protection. An included 9V battery protects during short-term power outages.
• Front-Loading Battery Speeds up replacement by eliminating the need to remove the unit from the ceiling or wall.
• Unique Battery Door Design Will not close if battery is not installed properly.
• Voice Warning Supplements warning from the traditional 85-decibel alarm by clearly stating the danger present, fire or carbon monoxide.
• Photoelectric Smoke Sensor May detect visible fire particles associated with slow smoldering fires sooner than an ionization sensor.
• Electrochemical CO Sensor Provides accurate and continual CO protection during the product™s life, remains stable during temperature and humidity changes and resists reactions to household gases that may cause false readings or reduce sensitivity.
• Smart Touch Button One button performs the following functions:

  • Activates the Hush® feature to temporarily silence nuisance alarms (will announce Hush mode activated, or Hush mode cancelled.)
  • Simultaneously tests the unit's electronics and verifies proper operation
  • Activates the peak level memory feature (will announce CO previously detected if unit has detected levels of 100 ppm or higher)
  • Resets the unit during a CO alarm (Unit will re-enter alarm within 6 minutes of reset if 70ppm or more of CO is present).
  • Silences a low battery chirp for up to 12 hours
  • Silences the end of life chirp for two days
• Tamper Resistant Unit will lock to mounting bracket and battery door will lock to deter theft or tampering.
• Green LED Will flash every 30 seconds to indicate proper operation.
• Red LED Flashes in conjunction with the alarm sounding.
• End of Life Signal Ten years after initial power, the unit will chirp twice every 30 seconds to indicate the need to immediately replace the alarm.
• Low Battery Signal Will chirp every minute and red LED will flash to indicate low battery condition.
• Interconnectable Will interconnect with up to 24 other devices (18 of which can be initiating) including smoke, CO and heat alarms.
• cUL- and CSA-listed

• Sealed 3V Lithium Battery Backup - 10-year* tamper proof battery eliminates need for battery replacement. Alerts user to replace alarm after 10 years of operation.
• Voice Warning - Warns of hazard by announcing Fire! or Warning, Carbon Monoxide.
• Intelligent Sensor Technology - Reduces nuisance alarms and offers fast response to real fires.
• Test/Hush Button Functions - A single button that tests alarm circuitry and temporarily silences nuisance alarms.
• Two LED Display - Red LED indicates alarm mode, Green LED indicates AC power is present.
• Peak Level Memory - Alerts user when the unit has detected CO concentrations of 100ppm or higher.
• Hush Feature Temporarily silences nuisance alarms for approximately 9 minutes and will not allow hush mode unless the unit is in alarm mode.

The Kidde CO120X can be used to activate auxiliary warning devices such as external bells and sirens, hallway or stairway lighting. This relay will only activate when it receives a CO signal from an interconnect Carbon Monoxide Alarm. When in the activated mode (as a result of a CO signal), this device will deactivate if it receives a smoke interconnect signal from a compatible device.
